WTB ST i23 / Formula DC20 / DC22 / DC2241 24''

$119.99 CAD

Sale Sold out

Title DC20, Wheel, Front, 24'' / 507, Holes: 32, QR, 100mm, Disc IS 6-bolt DC22, Wheel, Rear, 24'' / 507, Holes: 32, QR, 135mm, Disc IS 6-bolt, Shimano HG DC2241, Wheel, Rear, 24'' / 507, Holes: 32, QR, 141mm, Disc IS 6-bolt, Shimano HG

Quantity

ETRTO 507-23
Inner width: 23mm
Disc Brake Only
Drilled for Presta valve
TCS 2.0 Tubeless System compatible
Solid Strip (included)
32 holes

Front hub: Formula DC-20
QR 9x100mm (Quick Release binder included)
Anodized black with Laser Etched logo
6-Bolt ISO disc mount
Adjustable bearings
Rubber seal

Rear hubs options: Formula DC-22 (QR10x135mm) / DC-2241 (Boost QR 9x141mm)
Quick Release binder included
Anodized black with laser etched logo
6-Bolt ISO disc mount
Adjustable bearings
Rubber seal
Compatible with 8-11 speed MTB (12 speed HG with 1.85mm spacer, not included)

Assembled in North America by experienced wheelbuilders with Sapim stainless steel spokes (Black) and 14mm Brass Polyax Nipples (Black)

Attributes

Axle Type	QR
Depth	18mm
Rim Color	Black
Rim Construction	Double wall
Rim Drilling	32
Rim External Width	27mm
Rim inner width range	22-27.9mm
Rim Internal Width	23mm
Rim Material	Aluminum
Rim Model	WTB ST i23
Skewers Included	Yes
Spoke Type	Sapim
Valve	Presta
Wheel Diameter/ISO	24'' / 507
Wheel Tire Type	Tubeless Compatible
Wheel-Brake Comp.	Disc IS 6-bolt
